The SAS 9300-8e PCIe Gen 3.0 HBA with 8 external ports is ideal for increased connectivity and maximum performance for enterprise data center flexibility.
With increased bandwidth and IOPS performance over previous generations, the 9300-8e adapter delivers the performance and scalability needed by critical applications.
| Product | Manufacturer Part # | What's in the Box |
|---|---|---|
| SAS 9300-8e | H5-25460-00 | 9300-8e HBA, Low Profile Bracket, FH (attached) |
| Specification | Value |
|---|---|
| Lifecycle | Active |
| Brackets | Full height and low profile |
| Devices Supported | SAS/SATA: 1024 |
| External Connectors | 2 x4 SFF-8644 (ext HD) |
| External Ports |
8 |
| Generation | 12 Gb/s |
| Host Bus Type | x8 lane PCI Express 3.0 |
| I/O Controller | SAS3008 |
| Management Software | LSI Storage Authority (LSA), StorCLI (Command-Line Interface), HII (UEFI Human Interface Infrastructure) |
| MTBF | > 2,800,000 hours at 40° C |
| Operating Humidity | 5% to 90% Non-condensing |
| Operating Temperature°C | 0°C to 55°C |
| OS Support | Microsoft Windows, VMware vSphere/ESXi, Red Hat Enterprise Linux, SuSE Linux, Ubuntu Linux, Citrix XenServer, CentOS Linux, Debian Linux, Oracle Enterprise Linux, Fedora, FreeBSD. |
| Physical Dimensions | 2.6” x 6.6” |
| Regulatory Certifications | EMC: Class B-US (CFR 47, P15B); Canada (ICES-00); Japan (V-3/02.04); Europe (EN55022/EN55024); Australia/New Zealand (AS/NZS 3548); Korea (N-B 2-0001-404);Safety: EN60950; RoHS; WEEE |
| Typical Power | 14.5W |
| Warranty | 3 years, free technical support, advanced replacement option at broadcom.com/support/warranty/internal-raid-hba |
| What's in the box | 9300-8e HBA, Low Profile Bracket, FH (attached) |
